Description

FEATURES
High quality image with 4MP, 1/3″CMOS sensor
4MP (2560*1440)@25/20fps; 3MP (2304*1296)@30/25fps; 2MP (1920*1080)@30/25fps; 720P (1280*720)@30/25fps
Ultra 265, H.265, H.264, MJPEG
Smart IR, up to 30m (98ft) IR distance
Supports 128 G Micro SD card
Support PoE power supply
3-Axis
SPECIFICATIONS
Camera
Sensor 1/3″, 4.0 megapixel, progressive scan, CMOS
Minimum Illumination Colour: 0.01 Lux (F2.0, AGC ON)
0 Lux with IR on
Day/Night IR-cut filter with auto switch (ICR)
Shutter Auto/Manual, 1 ~ 1/100000s
Adjustment angle Pan: 0° to 360°, Tilt: 0° to 90°, Rotate: 0° to 360°
S/N >56dB
WDR DWDR
Lens
Lens Type 2.8mm @2.0, Fixed-focal
Lens Mount M12
Angle of View 97.0°(H) / 52.2°(V) / 107.5° (O)
DORI
DORI Distance Detect: 63.0m / Observe: 25.2m / Recognize: 12.6m / Identify: 6.3m
Illuminator
IR Range Up to 30m (98ft) IR range
Wavelength 850nm
IR On/Off Control Auto/Manual
Video
Video Compression Ultra 265, H.265, H.264, MJPEG
H.264 code profile Baseline profile, Main profile, High profile
Main Stream Frame Rate 4MP (2560 × 1440), Max 25fps
3MP (2304 × 1296), Max 30fps
1080P (1920 × 1080), Max 30fps
720P (1280 × 720), Max 30fps
Sub Stream Frame Rate D1 (720 × 576), Max 30fps
640 × 360, Max 30fps
2CIF(704 × 288), Max 30fps
CIF(352 × 288), Max 30fps
Video Bit Rate 128 Kbps~6144 kbps
U-code Supported
OSD Up to 4 OSDs
Privacy Mask Up to 4 areas
ROI Up to 8 areas
Motion Detection Up to 4 areas
White Balance Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2
Image Setting Image rotation, brightness, saturation, contrast, sharpness, gain adjustable by web browser
Digital noise reduction 2D/3D DNR
Smart IR Supported
Flip Normal/Vertical/Horizontal/180°
Dewarping NA
HLC Supported
BLC Supported
Defog Digital Defog
Events
Behavior Detection Cross line, intrusion(based on human body detection)
Motion detection, tampering alarm
General Function Watermark, IP address filtering, access policy, ARP protection, RTSP authentication, user authentication
Storage
Edge Storage Micro SD, up to 128GB
Network Storage ANR, NAS(NFS)
Network
Protocols IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, QoS, SSL/TLS, SNMP
Compatible Integration ONVIF (Profile S, Profile G, Profile T), API , SDK
User/Host Up to 32 users. 2 user levels: administrator and common user
Security Password protection, Strong password, HTTPS encryption, Export operation logs, Basic and digest authentication for RTSP, Digest authentication for HTTP, TLS 1.2, WSSE and digest authentication for ONVIF
Client Guard Station / Guard View / Guard Live
Web Browser Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below
Plug-in free live view: Chrome 57.0+, Firefox 58.0+, Edge 16+
Interface
Network 1 * RJ45 10M/100M Base-TX Ethernet
Certification
EMC FCC: FCC Part 15
Safety CE: EN 60950 ~ 1
UL: UL60950 ~ 1
IEC 60950 ~ 1
General
Power DC 12V±25%, PoE (IEEE 802.3af)
Power consumption: Max 4.0W
Power Interface Ø 5.5mm coaxial power plug
Dimensions (Ø × H) Φ118 × 97mm (Ø4.6” × 3.8”)
Weight 0.30kg (0.6lb)
Material Metal
Working Environment −30°C ~ 60°C (−22°F ~ 140°F), Humidity: ≤95% RH (non-condensing)
Storage Environment −30°C ~ 60°C (−22°F ~ 140°F), Humidity: ≤95% RH (non-condensing)
Surge Protection 4KV
Reset Button N/A
Ingress Protection Ingression protection: IP67
